Condition: New. A brand new one.
Brand Flomasta
Type: Pressure Reducing Valve with Gauge
MPN 41943-0001
Material: Brass
Country of Origin: Netherlands
NEW IN BOX
Kingfisher / Flomasta 41943-0001 Pressure-Reducing Valve with Gauge
Condition: New in box
Model / SKU: 41943-0001
Key Technical Specifications
Type A pressure-reducing valve (PRV) with integrated gauge
Body material: Brass
Connection size 22 mm compression
Operating water pressure 1 – 16 bar (maximum inlet rating)
Adjustable outlet pressure User-adjustable via control spindle; verify on gauge during commissioning
Temperature rating: up to 85 °C
Gauge-fitted pressure gauge for visual setting and verification
Pack size: 1 piece
Manufacturer's guarantee: 1 year
Country of manufacture: EU. Manufacturer listed: Netherlands.
Performance and Application Notes
Function: Reduces and stabilises incoming mains pressure to a safe, set outlet pressure to protect plumbing, boilers and appliances.
Applications: Domestic mains pressure control, boiler feed protection, small commercial systems.
Limitations: Not a temperature control device. Select PRV size and flow capacity appropriate to system demand.
Installation: Fit inline on the incoming supply, observing flow direction; isolate the mains before installation; commissioning and final adjustment should be performed by a qualified plumber. Re-check outlet pressure after system testing.
